ASTM D737 Air Permeability Tester Air Permeability Testing Equipment for Textile
It is used to rapid testing of the air permeability of various sheet materials such as coated fabrics, filter paper, filter media, and plastics.
Standards:GB/T5453 GB/T13764 ISO9237 ISO7231 ISO5636 BS5636 ASTM D737 DIN 53887 JIS L1096 BS5636
Features:
●High precision pressure sensor.
●Intelligent and flexible touch interface, the whole process of dynamic test is displayed.
●Full-scale automatic detection and conversion of air permeability and air permeability of various samples.
●Can arbitrarily set different national standard parameters and units, and the test results can be directly printed out without conversion.
●Measurement unit: mm/s, cfm, cm3/cm2/s, I/m2/s, I/dm2/min, m3/m2/min
Technical Parameter:
1 Pressure range: 0~4000Pa self-set pressure drop
2 Measurable air permeability: 0.1~12000mm/s
3 Measurement error: ≤±2%
4 Measurable fabric thickness: ≤15mm
5 Suction volume adjustment: data feedback dynamic adjustment
6 Sample area setting circle: 5cm2; 20cm2; 50cm2; 100cm2; optional
7 Sample diameter setting circle: Ф50mm (≈19.6cm2) Ф70mm (≈38.5cm2)
8 Nozzles: 11 in total
9 Data processing capacity: ≤1000 trials
10 Data output: high-definition touch screen display; built-in micro-printer;
11 Power supply: AC 220V±10V 50Hz
12 Power consumption: 200W
13 Weight: 80Kg
14 Appearance: 600×700×1100mm (L×W×H)
