Manual Rockwell Hardness Machine Digital Metals Hardness Testing Equipment
The Rockwell hardness testing method is characterized by simple operation, rapid measurement, and direct reading from a dial indicator or an optical projection screen or display.
Main Features :
High testing efficiency,with high accuracy hydraulic buffer,durable and reliable loading;
Direct dial readings,with scales of HRA,HRB and HRC;
Precise hydraulic buffers, loading smooth and adjustable speed;
Mechanical and manual testing mode,easy and simple operation,without electrical power supply;
Precision conforms to GB/T230.1/.2 National Standard,ISO 6508-2,ASTM E18.
Application:
It's suitable to determine the Rockwell hardness of ferrous, non-ferrous metals and non-metal materials. It can be widely applied in the Rockwell hardness testing for heat treatment materials, such as quenching, hardening and tempering, etc.
Specifications:
Measuring range | 20-88HRA, 20-100HRB, 20-70HRC |
Test force | 588.4, 980.7, 1471N (60, 100, 150kgf) |
Max. height of test piece | 170mm |
Depth of throat | 135mm |
Hardness resolution | 0.5HR |
Dimensions | 466 x 238 x 630mm |
Weight | approx. 65kg |
Standard accessories :
Large flat anvil: 1 pc.
Small flat anvil: 1 pc.
V-notch anvil: 1 pc.
Diamond cone indenter : 1 pc.
1/16" steel ball indenter: 1 pc.
Rockwell standardized block: 5 pcs
