ASTM D1525 Touch Screen Plastic VST Softening Point Tester Vicat/HDT Tester
The product is easy to operate, easy to use, stable in performance, high in product precision, and can monitor the test temperature and deformation in real time during the test; when the test is over, the system automatically stops heating, and can print test reports and test curves. This series of models is an essential instrument for self-inspection of various quality inspection units, colleges and universities and enterprises.
Specification:
1) Temperature control range: room temperature to 300 ° C;
2) Heating rate: 120 ° C / h, 50 ° C / h;
3) Maximum temperature error: ±0.5 °C;
4) Temperature measurement point: 1;
5) number of sample racks: 3;
6) Deformation measuring gauge: digital display dial gauge;
7) Deformation measurement range: 0 ~ 1.1mm;
8) Sample support span: 64mm, 100mm;
9) Maximum deformation measurement error: 0.01mm;
10) Heating medium: methyl silicone oil; (prepared by customers)
11) Cooling method: natural cooling above 150 °C, water cooling below 150 °C or natural cooling;
12) Instrument size: 810mm × 470mm × 780mm
13) Space required: 0.5m front and back, 1.5m left and right
14) Power: 2500VA 220VAC 50HZ
Configuration
1) 1 x Host
2) 3 x Sample holder
3) 3 x Hot deformation heads
4) 3 x Vicat pinion
5) 1 x Electric control box
6) 3 x Digital display dial gauge
8) 1 x Signal line
9) 1 x Screw screwdriver
10) 1 x Weight set
Name
Speci fication | A | B | C | D | E | F | G | H | I | T | W |
Weight（g） | 1000 | 900 | 500 | 200 | 100 | 50 | 20 | 10 | 5 | 2 | 60(Load bar) |
Pcs | 12 | 3 | 3 | 6 | 3 | 3 | 6 | 3 | 3 | 6 | 3 |
Remarks: Users need to have cooling water source and ventilation smoke exhaust equipment
ASTM D1525 Touch Screen Plastic VST Softening Point Tester Vicat/HDT Tester
The product is easy to operate, easy to use, stable in performance, high in product precision, and can monitor the test temperature and deformation in real time during the test; when the test is over, the system automatically stops heating, and can print test reports and test curves. This series of models is an essential instrument for self-inspection of various quality inspection units, colleges and universities and enterprises.
Specification:
1) Temperature control range: room temperature to 300 ° C;
2) Heating rate: 120 ° C / h, 50 ° C / h;
3) Maximum temperature error: ±0.5 °C;
4) Temperature measurement point: 1;
5) number of sample racks: 3;
6) Deformation measuring gauge: digital display dial gauge;
7) Deformation measurement range: 0 ~ 1.1mm;
8) Sample support span: 64mm, 100mm;
9) Maximum deformation measurement error: 0.01mm;
10) Heating medium: methyl silicone oil; (prepared by customers)
11) Cooling method: natural cooling above 150 °C, water cooling below 150 °C or natural cooling;
12) Instrument size: 810mm × 470mm × 780mm
13) Space required: 0.5m front and back, 1.5m left and right
14) Power: 2500VA 220VAC 50HZ
Configuration
1) 1 x Host
2) 3 x Sample holder
3) 3 x Hot deformation heads
4) 3 x Vicat pinion
5) 1 x Electric control box
6) 3 x Digital display dial gauge
8) 1 x Signal line
9) 1 x Screw screwdriver
10) 1 x Weight set
Name
Speci fication | A | B | C | D | E | F | G | H | I | T | W |
Weight（g） | 1000 | 900 | 500 | 200 | 100 | 50 | 20 | 10 | 5 | 2 | 60(Load bar) |
Pcs | 12 | 3 | 3 | 6 | 3 | 3 | 6 | 3 | 3 | 6 | 3 |
Remarks: Users need to have cooling water source and ventilation smoke exhaust equipment
