GB/T1232 Mooney Viscometer Tester Rubber Mooney Viscometer For Lab

GB/T1232 Mooney Viscometer Tester Rubber Mooney Viscometer For Lab

Introduction

Mooney viscometer is suitable for the determination of various kinds of unvulcanized natural rubber, synthetic rubber and reclaimed rubber Mooney viscosity, the scorch time and curing index.

Accessories

A. One copy of one-year warranty and one English operation manual.

B. A special test software for rubber Mooney viscometer.

Main Technical Parameters

A. Temperature range 0-200°C

B. Temperature measurement accuracy ≤±0.3°C

C. Control accuracy ≤±0.3°C

D. Temperature Resolution 0.1°C

E. Torque range 0-100 Mooney

F. Calibration accuracy 100±0.5 Mooney

G. Rotor speed 2±0.02 rev/min

H. Measurement time 0-200 points Resolution 1 second

I. Ambient temperature 0-35°C

J. Relative humidity <80

K. Test pressure 11.5KN ±0.5KN

L. Gas distribution 0.45-0.6MPA

M. Power supply AC 220V 1KVA

N. Machine size: about 660×570×1300mm

O. Machine weight: about 210Kg
