ISO 2507 Vicat Softening Testing Machine Plastics Vicat Test Apparatus With ISO
Application:
With sample rack lifting function, the sample holder can be lifted or lowered at the beginning or end of the test. The machine is mainly used for heat distortion temperature and Vicat softening of non-metallic materials such as plastic, rubber, nylon, electrical insulating materials, etc. Determination of point temperature.
Standards:
Standards:GB/T 1633, GB/T 8802, GB/T 1634, ISO 2507, ISO 75, ISO 306, ASTM D 1525, ASTM D 648.
Specification:
1) Temperature control range: room temperature to 300 ° C;
2) Heating rate: 120 ° C / h, 50 ° C / h;
3) Maximum temperature error: ±0.5 °C;
4) Temperature measurement point: 1;
5) number of sample racks: 3;
6) Deformation measuring gauge: digital display dial gauge;
7) Deformation measurement range: 0 ~ 1.1mm;
8) Sample support span: 64mm, 100mm;
9) Maximum deformation measurement error: 0.01mm;
10) Heating medium: methyl silicone oil; (prepared by customers)
11) Cooling method: natural cooling above 150 °C, water cooling below 150 °C or natural cooling;
12) Instrument size: 810mm × 470mm × 780mm
13) Space required: 0.5m front and back, 1.5m left and right
14) Power: 2500VA 220VAC 50HZ
Configuration
1) 1 x Host
2) 3 x Sample holder
3) 3 x Hot deformation heads
4) 3 x Vicat pinion
5) 1 x Electric control box
6) 3 x Digital display dial gauge
8) 1 x Signal line
9) 1 x Screw screwdriver
10) 1 x Weight set
Speci fication | A | B | C | D | E | F | G | H | I | T | W |
Weight（g） | 1000 | 900 | 500 | 200 | 100 | 50 | 20 | 10 | 5 | 2 | 60(Load bar) |
Pcs | 12 | 3 | 3 | 6 | 3 | 3 | 6 | 3 | 3 | 6 | 3 |
Remarks: Users need to have cooling water source and ventilation smoke exhaust equipment
