1000kg Paper Tube Compressive Strength Testing Machine AC220V 50Hz
Application:
This machine is the ideal test auxiliary appliance for paper, packaging, scientific,research, quality and other industries and department.it is used to test tube, yarn tape, paper tins, synthesis of tins, horizontal compressive strength. Applicable to paper tubes with an outer diameter of 200mm, also known as paper tube pressure tester, paper tube compression tester, is the basic instrument for paper tube compression resistance test, using high-precision sensors, high-speed processing chip design to ensure sampling accuracy.
Specification:
Model | |
Capacity | 200,500,1000kg |
Induction | Force sensors |
Displayer | ZL-2000 |
Resolution | 1/20000 |
Accuracy | ± 0.5 % |
Units switch | Kgf, Lbf, N.( Optional) |
Testing speed | 10 ~ 200 mm/min |
Speed input methods | Revolving |
The pressure plate area | 30*30 cm |
The pressure plate spacing | 30 cm Or designated |
Dimension | 85×65×80cm |
Weight | 130 kg |
Power | AC220V 50Hz (According to national or specified) |
1000kg Paper Tube Compressive Strength Testing Machine AC220V 50Hz
Application:
This machine is the ideal test auxiliary appliance for paper, packaging, scientific,research, quality and other industries and department.it is used to test tube, yarn tape, paper tins, synthesis of tins, horizontal compressive strength. Applicable to paper tubes with an outer diameter of 200mm, also known as paper tube pressure tester, paper tube compression tester, is the basic instrument for paper tube compression resistance test, using high-precision sensors, high-speed processing chip design to ensure sampling accuracy.
Specification:
Model | |
Capacity | 200,500,1000kg |
Induction | Force sensors |
Displayer | ZL-2000 |
Resolution | 1/20000 |
Accuracy | ± 0.5 % |
Units switch | Kgf, Lbf, N.( Optional) |
Testing speed | 10 ~ 200 mm/min |
Speed input methods | Revolving |
The pressure plate area | 30*30 cm |
The pressure plate spacing | 30 cm Or designated |
Dimension | 85×65×80cm |
Weight | 130 kg |
Power | AC220V 50Hz (According to national or specified) |
Guangdong Hongtuo Instrument Technology Co.,Ltd has been specializing in density testing field on developing, innovating and producing since the year it was establised.
