1.Product Model：HT-1600-EL

2.Application Field：

Electric Izod Impact Specimen Notch Sample-making Machine is the sampling machine producing notch sample used by charpy and izod impact tester to do the test of impact toughness of non- metallic materials. It can clamp 20 samples per time; make more than 60 notches per 10 minutes.

The size of Electric Izod Impact Specimen Notch Sample-making Machine  is accurate, and has much effective, greatly reduced the difficulties of operation.

3.Basic Standard：

（1）ISO179—2010 Plastic Determination of impact properties of simply supported beams

 The 1st part：Non-instrumental impact test；

（2）German version EN ISO 179-1:2010；

（3）ISO180—2001ISO 180-2000 Plastic--Determination of Izod impact strength；

（4）GB/T1043-2008 Plastic Determination of impact properties of simply supported beams

 The 1st part :Non-instrument impact test；

（5）GB/T1843—2008 Plastic  Determination of impact strength of cantilever beam

4.Specifications：

1.Workbench stroke：＞160mm

2.Feed speed：30mm/min

3.Sample type：Ⅰmodel

4.Notch type: according to tool specifications

 A Model 45°±1° R=0.25±0.025mm

B Model 45°±1° R=1.0±0.025mm

C1 Model Notch thickness :0.8±0.1mm

C2 Model Notch thickness:2.0±0.2mm

5.Feed amount: according to the standard

6.Outer Dimension：600mm×270mm×300mm

7.Power supply voltage: 220V, single-phase three-wire system
