Environmental ISO4892 Solar Simulator Xenon Arc Test Chamber
Environmental ISO4892 Solar Simulator Xenon Arc Test Chamber Environmental ISO4892 Solar Simulator Xenon Arc Test Chamber
Environmental ISO4892 Solar Simulator Xenon Arc Test Chamber Environmental ISO4892 Solar Simulator Xenon Arc Test Chamber

loading

Environmental ISO4892 Solar Simulator Xenon Arc Test Chamber

Share to:
sharethis sharing button
VOLUME(L):150
Inner size: WHD(cm):50*60*50
External size: WHD(cm):105*185*115
Temperature range:0℃~80℃, adjustable
  • DH-XD-150

  • Dahometer

  • 1 set

  • About 5 days

  • 1 year,Lifelong maintenance

  • T/T, Western Union...

  • Negotiable

Availability:
Quantity:

Environmental ISO4892 Solar Simulator Xenon Arc Test Chamber


Description:

xenon test chamber is a comprehensive climate testing machine, can do climatic aging test and the lightfastness test of polymer materials which exposed at simulated sunlight. It simulates the light, temperature, rainfall, condensing, humidity to test the materials; it can be used for choosing new materials, improving existing materials, or assessment of change in material composition.


Advantages of Xenon Arc Accelerated Aging Test Chamber:

  • Using water cooled  xenon lamp, It has better heat dissipation.

  • Programmable touch screen, save time, easy to operate and High precision.

  • Standard and Customized.


Features:



1.Adopt the long axis fan motor,anti high and low temperature stainless steel multi-blades wheel,have good convection.and vertical diffusion cycle.



2.Double-layer anti-high temperature sealing strip has been used between the door and the box.to make sure the leakproofness for the testing area.



3.Adopt non-counteractive door knob,more easy operation.



4. Adopt high quality fixable PU running wheel of the bottom of machine.



5.Adopt multi-layer hollow tempered glass inspection window.(can observe the testing procedure clearly)



6.Irregular shape sample holder,make the installation of testing specimen more easier.and convenient to be used.



7. The working life of xenon lamp is determined by the radiation level.normal service life of lamp is 1600 hours.Lamp is easy to be changed.The effective filter can make sure spectrum demanded can be offered.



Specification:

Model

DH-XD

-80

-150

-225

-408

-800

-1000

Inner size: WHD(cm)

40*50*40

50*60*50

60*75*50

60*85*80

100*100*80

100*100*100

External size: WHD(cm)

105*185*115

105*185*115

115*195*115

135*210*120

155*230*145

155*230*165

Temperature and humidity uniformity

± 2°C; ± 3%RH

Temperature range

0℃~80℃, adjustable

Humidity range

30%~98%R.H

Type of light source

 imported air-cooled full solar spectrum long arc xenon lamp (average service life is around 1600 hours)

Rainfall time

1~9999min, adjustable

Rainfall cycle

1~240min,interval is adjustable

Wavelength

290nm~800nm

Source irradiance

290~800nm:   100~600w/m2
            300~890nm:  200~1200w/m2
            340nm:       0.3~1.2w/m2
            420nm:       20~120w/m2

Distance from the center of the arc to the sample holder

 350380mm

Sample rotating basket speed

≥1r/min

Water spray cycle

Water spray time: 0 ~ 99h59min, continuously adjustable;                                                                   Stopping time: 0~99h59min, continuously adjustable

Light time

Continuous programming

Blackboard temperature

85±3℃

Cooling method

Mechanical refrigeration air cooling

Xenon lamp light

Xenon long-arc lamp, 1.8KW±10%, 290-800nm, 1200W/m2

Xenon lamp light quantity

1PCS

2pcs

3 PCS

Box material

Stainless Steel SUS304#

Control and cooling system

Korea TEMI programmable controller

Power (w)

4500

5500

6000

11800

13500

14000

weight (kg)

230

230

300

450

550

680
