Manual Video Measuring Equipment High Precision Image Measuring Machine
Product Features:
1.High precision and high strength machine:00 marble base / upright column / workable,high precision and good stability.
2.XYZ three axis imported precision V type guide rail / imported optic axis drive system.long service life.good stability.
Specification:
Model | DH-2010F | DH-3020F | DH-4030F | DH-5040F | |
Worktable | Metal table’s size(mm) | 350*220 | 450*350 | 550*450 | 700*600 |
Glass table’s size(mm) | 230*130 | 330*230 | 430*330 | 530*430 | |
X/Y axis travel(mm) | 200*100 | 300*200 | 400*300 | 500*400 | |
Z axis travel | Effective space is 245mm,focusing stroke is 200mm,and working distance is 95mm | ||||
Drive type | X/Y axis rod drive,Z axis optical axis drive | ||||
Weight(kg) | 170 | 260 | 300 | 500 | |
Dimension(L)*(W)*(H) | 500*700*1100 | 600*750*1100 | 700*900*1150 | 850*1050*1200 | |
Measuring servo drive system | Optical scale resolution:X/Y/Z axis 0.0005mm(0.5um) | ||||
Measuring accuracy:≤3um + L/200 repeatability accuracy:≤3um+L/200(L be regarded as measured length, units: mm) | |||||
Versatile data processor can measures points,lines,loops,circles,angles.etc. | |||||
Image System | Camera :SONY1 / 3" Color CCD Camera | ||||
Lens magnification :0.7~4.5X WD:95mm | |||||
Can match 0.5x objective lens,total magnification:15-115x | |||||
Can match 2x objective lens,total magnification:60-460x | |||||
LIght system | Surface light and projection light,cold light,long life,brightness adjustable,Surface light and transmission light are used LED,Power:220/110V(AC),50HZ 30W | ||||
Manual Video Measuring Equipment High Precision Image Measuring Machine
Product Features:
1.High precision and high strength machine:00 marble base / upright column / workable,high precision and good stability.
2.XYZ three axis imported precision V type guide rail / imported optic axis drive system.long service life.good stability.
Specification:
Model | DH-2010F | DH-3020F | DH-4030F | DH-5040F | |
Worktable | Metal table’s size(mm) | 350*220 | 450*350 | 550*450 | 700*600 |
Glass table’s size(mm) | 230*130 | 330*230 | 430*330 | 530*430 | |
X/Y axis travel(mm) | 200*100 | 300*200 | 400*300 | 500*400 | |
Z axis travel | Effective space is 245mm,focusing stroke is 200mm,and working distance is 95mm | ||||
Drive type | X/Y axis rod drive,Z axis optical axis drive | ||||
Weight(kg) | 170 | 260 | 300 | 500 | |
Dimension(L)*(W)*(H) | 500*700*1100 | 600*750*1100 | 700*900*1150 | 850*1050*1200 | |
Measuring servo drive system | Optical scale resolution:X/Y/Z axis 0.0005mm(0.5um) | ||||
Measuring accuracy:≤3um + L/200 repeatability accuracy:≤3um+L/200(L be regarded as measured length, units: mm) | |||||
Versatile data processor can measures points,lines,loops,circles,angles.etc. | |||||
Image System | Camera :SONY1 / 3" Color CCD Camera | ||||
Lens magnification :0.7~4.5X WD:95mm | |||||
Can match 0.5x objective lens,total magnification:15-115x | |||||
Can match 2x objective lens,total magnification:60-460x | |||||
LIght system | Surface light and projection light,cold light,long life,brightness adjustable,Surface light and transmission light are used LED,Power:220/110V(AC),50HZ 30W | ||||
