Mini Desktop Plastic Injection Molding Machine For Plastic

Share to:
sharethis sharing button
Application:novelty items, custom components for model cars, boats
Advantages:Stamping pressure, Temperature, transfer time ,adjustable
Maxi. temperature:490℃
Plunger diameter:30mm
  • DH-IM

  • Dahometer

  • 1 set

  • 5-7 days

  • 1 years,Lifelong maintenance

  • TT/Western Union/Paypal etc

  • Negotiable

Availability:
Quantity:

Mini Desktop Plastic Injection Molding Machine For Plastic

Introduction:



This very versatile machine is extremely easy to operate and can be used for short production runs as well as prototype models with cheap cast resin moulds

Moulds materials:  Can use copper, brass, aluminium and cast types, because of low pressures used


Advantages:

1. Pressure strong, stable.

2. Stamping pressure, Temperature, transfer time ,adjustable

3. Adjustable mechanical paper feeding and receiving



Main parameters:



Maxi. temperature

490℃

Plunger diameter

30mm

Maximum compressing stoke

135mm

Heating cavity size

30*70mm

Maximum shot volume

30cm3(30g)

Mold max. size

120*120*80mm

Base size

400*200mm

Vise stoke size

135mm*115mm

Machine weight

55kg

Power supply

400w

Voltage

220V/230V, 50/60HZ



Configuration:



Machine host

Thermostat

Power button

Power line including fuse

Switching Power Supply

Heating relay

Temperature probe

Fever laps
